B-ONE Series
B ONE PLUS LTE
- 2x Ethernet WAN
- 4x Ethernet LAN
- 1x Embedded 4G LTE Modem (APAC & EMEA/ CAT-4)
- 2×2 MIMO Simultaneous Dual-Band, Wi-Fi 6
- 1Gbps Router Throughput
- Full antenna set
AED 1,500 EX VAT
| Weight | 0,76 kg |
|---|---|
| Dimensions | 26,2 × 16,1 × 3,35 cm |
| WAN Interface | 2x 10/100/1000M Ethernet 1x Embedded Cellular Modem with a Redundant SIM Slot 1x USB-C Interface |
Antenna Connectors | 2x SMA Cellular Connectors 2x RP-SMA Wi-Fi Antenna Connectors |
| LAN Interface | 4x 10/100/1000M Ethernet | Power Input | Power Port: 10V – 30V DC AC Adapter: AC Input 100V–240V / DC Output 12V |
| Wi-Fi Interface | Simultaneous Dual-Band (2.4GHz / 5GHz) Wi-Fi 6, 2×2 MIMO Wi-Fi WAN and/or AP |
Power Consumption | 6W (nominal), 17W (max. without USB-C output ⁶) |
| SpeedFusion features | Hot Failover ² / Smoothing ² / Bandwidth Bonding ² | Dimension | 10.31 x 6.33 x 1.31 inches / 262 x 161 x 33.5 mm |
| Number of SpeedFusion VPN Peers | 2 / 5 / 10 / 20 ³ | Weight | 1.7 pounds / 761 grams |
| Router Throughput | 1Gbps | Operating Temperature | -40° – 113°F / -40° – 45°C |
| SpeedFusion VPN Throughput – No Encryption – 256-bit AES |
400 Mbps 200 Mbps |
Humidity | 10% – 90% (non-condensing) |
| Recommended Users | 1-150 | Certifications | FCC, CE, RoHS |
| AP Controller | Standard | Package Content | 1x B One Plus 2x LTE/5G Antennas 2x Dual Band Wi-Fi Antennas 1x 12V 3A 4 Pin Power Supply (ACW-672) |
| Maximum Number of AP Supported | 30 / 50 ⁴ | SIM Options | Nano-SIM (4FF) Peplink eSIM ⁷ BYO eSIM (2 profiles) ⁷ RemoteSIM from SIM Injector ⁸ FusionSIM ⁸ |
| Cellular Data Rate ⁵ (Downlink / Uplink) | CAT-4: 150 Mbps / 50 Mbps | Warranty | 1-Year Limited Warranty |
1 Requires LIC-DOC license and firmware 8.5.2 or above to enable Docker.
2 Requires a PrimeCare subscription, complimentary for the first year.
3 5 SpeedFusion VPN Peers are enabled with PrimeCare Subscription. 10 or 20 SpeedFusion VPN peers can be enabled with software license (PVN-LC-10 and PVN-LC-20). 4 Available with licence add-on (AP-LC-50).
5 Theoretical maximum data rates.
6 USB-C Output : 5V at 2A can be delivered to power the MAX Adapter or other USB dongles for USB WAN.
7 Models with selected SKU support eSIM. Details can be found
8 RemoteSIM and FusionSIM are compatible with hardware version 2 or above.
